Woodworking Jigs and Rockler JIG IT®

Innovative jigs and equipment designed by Rockler make fast, accurate work of installing Blum concealed hinges, drawer slides, knobs and pulls, shelf brackets, crown molding, Minifix knock-down hardware, and more!

JIG IT®
Shelving Jig

Crown Molding
Compound Miter Jig

Multi Tool Rail JIG IT®
for Concealed Hinges

JIG IT ® for Concealed Hinges

Our innovative JIG IT System lets you quickly and easily locate, center and a drill cup holes on cabinet doors for fully concealed hinges. The Concealed Hinge JIG IT is ideal for drilling individual hinge cup holes. To drill the mounting plate holes, use our Mounting Plate JIG IT template to accurately positions holes for mounting plates.

Product Details:

Drills concealed hinge cup holes individually.

Perfect for smaller jobs where accuracy is needed, but set up is not a concern.

Package includes an alignment plate, bit guide, spring, stop collar and clamp.

Drill bits and mounting plate JIG IT templates sold separately.

Choose from (4) Long Shank Carbide Hinge Cup Forstner Bits (91841, 10117, 10104, 20563) to drill holes for the hinge cup as illustrated to the left.

» Use Concealed Hinge Jig IT for mounting cup holes

» Use the Mounting Plate Jig IT for hinge mounting plate holes

Mounting Plate for JIG IT Templates


The Mounting Plate for JIG IT Template accurately positions holes for mounting plates. Also for use with rail system for positioning. Requires self centering bit #68991.

Choose from (5) different templates.

Applicable mounting plates are listed with each hinge.

1) Jig IT Mounting Plate Template A - 31350
    » 120° Clip Top Hinges
    » 170° Clip Top Hinges (Full of Half Overlay)
    » 90° Mini Clip-On Hinges
    » 95° Thick Door Clip Top Hinges
    » 110° Cross-Corner Clip Top Hinges
    » 95° Blind-Corner Clip TopHinges
    » 60° Bi-Fold Hinges
2) Jig IT Mounting Plate Template B - 31098
    » 170° Clip Top Hinges - Inset only
3) Jig IT Mounting Plate Template C - 31084
    » 165° Zero Clearance Hinges
4) Jig IT Mounting Plate Template D - 31511
    » 120° Clip Top 3-way Face Frame Hinges
5) Jig IT Mounting Plate Template E - 31357
    » 105° 2-way Face Frame Hinges

Multi Tool Rail JIG IT

For drilling multiple hinge cup holes with a single set up. Rockler's newest system lets you combine two or more original Concealed Hinge JIG IT's together for drilling all the hinge cups on one door with a single set up. It is the right choice for creating consistency from one door to the next.

Now available as a value priced Master Pack for drilling two cup holes per door! Additional Concealed hinge JIG IT's can be added for doors requiring three or more hinges. The Master Pack includes a 30'' rail, two alignment plates, one bit guide, and a stop block for positioning the jig on a door. Choose the appropriate drill bit. Mounting plate JIG IT templates are also available for specific hinges, and can be used on the 30'' rail for matching the position of the hinge cups on the door.

» 35MM Hinge Hole Repair Kit

Kit includes material to repair two hinge sets. Your choice of Cherry, Maple and Oak.

More Jigs and Tools at Rockler.com


EasyCoper
for Crown Molding

Kreg Universal Drawer
Slide Mounting Jig

Kreg Drawer
Mounting Brackets

JIG IT ®
Mortising System

Drawer Pull
JIG-IT® Template

Drawer Slide
IG IT®

Rockler Veneer
Trimming Guide

Router Bit
Set-Up Jigs

Hinge Cup
Drilling Jigs

Minifix JIG IT®
Template

Concealed Hinge
Router Jig-It

Soss
Routing Jig

Pen Blank
Drilling Jig

35mm Euro Hinge
Drilling Jig

3/8'' Beadlock
Basic Starter Kit
